SRM - rotors

The SRM is Hunter’s shortest-range rotor, and was designed to offer a convenient and efficient alternative to spray heads. It is capable of working in tandem with larger rotors to combine big and small areas in a single zone. Utilizing the SRM where appropriate results in fewer sprinklers performing more efficient work at a more economical price. The SRM features a rack of six water-efficient nozzles—all of which can be easily identified by its flow rates and installed and changed quickly and easily. This versatile rotor also includes a radius adjustment feature that fine-tunes the spray to keep water off driveways, walks, and other non-landscaped surfaces.










Features                                                               Specification

  • Model: 4"

  • Arc setting: 40 to 360 degrees

  • Nozzle choices: 6

  • Nozzle range: 0.50 to 3.0

  • Standard factory installed nozzle: 3.0 only

  • Through-the-top arc adjustment

  • Quick check arc mechanism

  • Water lubricated gear-drive

  • Warranty period: 1 year

  • Radius: 15' to 30'
  • Flow rate: 0.42 to 3.4 GPM
  • Recommended pressure range: 30 to 50 PSI
  • Operating pressure range: 20 to 100 PSI
  • Precipitation rates: 0.45 in/hr approx.
  • Nozzle trajectory: 18 degrees approx.


SRM Model Chart






SRM-04

Overall Height 6-5/8"
Pop-up Height 4"
Exposed Diameter 1-1/8"
Inlet Size 1/2" Female NPT


SPECIFICATION BUILDER


MODEL

STANDARD FEATURE

SRM-04 = 4" Pop-up Adjustable arc, 6 standard nozzles


EXAMPLE

SRM-04 4" pop-up, adjustable arc
