Wind turbine 30KW

Model: H10.0-30kW
Hummer 30kWwind turbine can be applied in both on-grid and off-grid systems. The output is single-phase or three-phase AC and it can drive load below 30kW.


1.SCF Supercritical generator
Hummer’s wind generator adopts SCF supercritical technology which won a gold award in the 37th Salon Eureka in Brussels. This technology significantly reduces generator’s weight and size down to 25% to 30% of the traditional one, and the production efficiency is 25% to 30% higher. This ensures that the generator functions perfectly in small wind condition.

2. SKF bearings

Hummer 30kW wind turbine adopts the NSK bearings which are produced by the renowned bearing manufacturer in the world, with the perfect internal geometric structure, known for its life-time endurance and reliable quality. As well as enabling smooth and quiet rotation, they also perform an important function by taking on the motor's load.

3.PLC integrated with Siemens module

Hummer wind turbine’s controlling system adopts the smart touch-screen PLC (Programmable Logic Controller) which is integrated with Siemens controllig unit. The PLC will alarm and adjust the abnormal running status of the wind turbine automatically both timely and efficiently. Siemens module offers high reliability to our PLC and its customers worldwide can testify for that.

4. Low noise

The design of the rotor blade of Hummer wind turbine absorbs the highlights of the small aircraft’s airfoil, which is compliance with the aerodynamic standards. It provides a more aesthetic look and a higher efficiency and reduces the noise production as much as possible.

5.Triple braking protection

Hummer 30kW wind turbine adopts the triple braking protection system, which are the yawing mechanism, the electromagnetic braking system and the hydraulic braking system to regulate the rotation of the wind turbine. It is easy and convenient to shut down the whole system both manually and automatically.

                                           Rated power (W)                                            30000
                                           Maximum output power (W)                            45000
                                           Battery bank voltage (VDC)                             360
                                           Cut-in wind speed (m/s)                                  2.5
                                           Rated wind speed (m/s)                                  11
                                           Working wind speed (m/s)                              3-25
                                           Survival wind speed (m/s)                                50
                                           Generator efficiency                                        >0.92
                                           Wind energy utilizing ratio (Cp)                        0.42
                                           Generator type                                               Permanent Magnet Alternator
                                           Generator weight (kg)                                     800
                                           Blade material/quantity                                   GRP/3
                                           Blade diameter (m)                                         Ф10.0
                                           Overspeed control                                          Yaw + Electromagnetism brake+ hydraulic brake
                                           Shutting down method                                    Manual + Automatic

Additional Information

price:  $23 000 -
*Generating system
(FOB Shanghai).

price:  $49 455 -
* Generating system,
* Rectifier,
* PLC controller,
* Dumping load inverter,
* no Battery bank
(we suggest the customers to buy the battery bank in their local market
(FOB Shanghai).
